SPRAY DRYER PHOTO GALLERY

Below are selected pictures of SDS spray dryers in various stages of fabrication, installation, and start up.  Click on a picture for an enlarged view.



An 11 foot diameter ceramics spray dryer on it's way to our customer.

The 11 foot diameter ceramics spray dryer during installation.

The 11 foot diameter ceramics spray dryer ready to make powder.

First batch of ceramic powder on a successful startup!

The top of the installed 11 foot diameter ceramics spray dryer and air heater.

The 11 foot diameter ceramics spray dryer, fuel train, and remote HMI station.

A twelve foot diameter catalyst spray dryer in the fabrication shop.

The twelve foot diameter catalyst spray dryer loading onto truck in the fabrication shop.

The twelve foot diameter catalyst spray dryer ready to roll.

A Model 48 spray dryer with chamber bottom product separation, cyclone, and bag house collection.

A custom layout Model 48 spray dryer to extening through an existing floor.

A custom layout Model 48 spray dryer to extening through an existing floor.

A Model 60 spray dryer in fabrication.

A Model 60 spray dryer, cyclone, and air heater loaded and ready to ship to our customer.

Another Model 48 spray dryer installed and ready to produce.

Twelve foot diameter spray dryer loaded at the fab shop.

Crane lifting twelve foot diameter dryer off truck at Customer site.

Twelve foot diameter spray dryer lowered through roof into steel.

Nine foot diameter ceramics spray dryer lifted for installation through roof.

Nine foot diameter ceramics spray dryer lowered into position.

Model 48/72 hybrid spray dryer before shipment to our customer.

Access door on the Model 72 size spray dryer chamber with welded insulation cladding.

Model 72 spray dryer for ceramics during shop fit up.

A thirty foot diameter spray dryer with rotary atomization.

A twenty foot diameter spray dryer checked for proper fit up during fabrication.

The twenty foot spray dryer shipping in sections from the fabricator for field assembly.

The twenty foot diameter, pressure nozzle spray dryer being erected.

The twenty foot diameter spray dryer ready for commissioning.

Spray dryer for bulk acetaminophen being set in place.

Eight foot diameter spray dryer for ceramics arrives at site for installation.

Ceramics spray dryer lowered into place.

Model 72 mixed flow spray dryer for ceramics at fab shop during shop fit up.

Alumina spray dryer installed and ready for start up.

Aluminum chlorohydrate spray dryer with cyclone and wet scrubber.

Spray dryer being lowered through the roof into place.

The SDS spray dryer access door is made for ease of use and long term durability.

Spray dryer shown with product cooling conveying line from main cyclone.

Laundry detergent spray dryer assembled at site and ready for installation.

First batch of quality spray dried product!!

Spray dryer pressure nozzle access platform.

Chamber bottom separation on spray dryers where a portion of the spray dried product exits the spray drying chamber.

View of a nozzle spray dryers feed header, with flexible hose connections and valves for isolating each nozzle during operation.

Tall form pressure nozzle spray dryer for 300 micron particles.

A spray dryer for use with rotary atomization being fabricated.

Pressure nozzle spray dryer for 300 micron precipitated silica.
